Bearing Price List 539/580K NSK Spherical Roller Bearing
Keywords:
Category:
Spherical Roller Bearing
Bearing Price List 539/580K NSK Spherical Roller Bearing
Detail
Bearing description:
The spherical roller bearing has a double row of rollers, with one common spherical raceway in the outer ring and two raceway in the inner ring and inclined at an Angle relative to the bearing axis. This ingenious structure makes it self-aligning, so it is not easy to be affected by the Angle of shaft and bearing box on the error or shaft bending, suitable for installation error or shaft deflection caused by Angle error. The bearing can bear radial load as well as bidirectional axial load.
Main uses:Paper making machinery, reducer, railway vehicle axle, rolling mill gearbox bearing seat, rolling mill roller, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial reducer, vertical self-aligning bearing with seat.
Mainly cage:
Stamped steel reinforced cage (suffix E, very few in China).
Stamped steel plate cage (suffix CC), glass fiber reinforced polyamide 66 cage (suffix TVPB), machined brass two-piece cage (suffix MB).
Machined brass integral cage (suffix CA), stamping steel cage for vibration occasions (suffix JPA).
Brass cage for vibrating occasions (suffix EMA). The same structure, bearing on the code may be different.
According to user requirements, spherical roller bearings with inner ring oil holes can also be supplied. In order to facilitate the installation and replacement of bearings by customers, spherical roller bearings with taper inner holes can also be provided.The taper hole taper is 1:12. , The suffix code is K to indicate that in order to meet the requirements of special users, bearings with an inner hole taper of 1:30 can also be provided, and the suffix code is K30. Bearings with a tapered inner hole can be directly mounted on the tapered journal with a lock nut, or can be mounted on the cylindrical journal with the aid of an adapter sleeve or a withdrawal sleeve.
